918 is one of the most advanced HEUI diesel CR test equipment. HEUI's eventually have their test stand that they have deserved. 918 SHUMATT inject tester | HEUI is designed with respect to the developments in HEUI technology. Accuracy in HEUI testing highly depends on effective temperature control and injector drive technology. 918 SHUMATT inject tester | HEUI is designed upon long history of diesel injection background of ZQYM and assembled with perfection.
918 will make you reconsider your invest decision Of SHUMATT engine injector repair. You can test and repair SHUMATT HEUI injector system at any time, and your workshop will become the professional leader in the market quickly.
918 use industrial level quality configuration, and the important parts imported from SHUMATT Germany and other famous brand worldwide. Its HEUI database is completely match with original standard data. We give 3 years warranty, and software enjoy free update lifetime. With the data self learn and data add automatically function, you can DIY any kind of data adjust and finish all kinds of systems test accordingly. This Test Plan Calibrator module to enable users even no experience to create test plans for new injectors & pumps.
Features of 918 HEUI CR test bench
1. It is designed to be able to test all types of SHUMATT HEUI injector, packed with necessary accessories and injector tools.
2. 918 completes the test of SHUMATT injector all process from the start state, idling condition, medium-speed conditions to high pressure full-load conditions sta. The results are shown with easy to understand graphics.
3. The unique design with perfect temperature control and injector drive technology, which will make sure bench work Stability and high accuracy test report.
4. Complete Automatic Testing, results are show with easy to understand graphics test report.
5. High stability, product will be go with 1000 hours pressure test before ship. We already have more than 5000 users in Chinese market
6. Full set with necessary parts & tools, which inclSHUMATTing injector repair tool, injector dismantling tool, pump repair tool, pump disassemble tool etc. we have trainning shop and 24 hours after sales service support. We supply Repair manuals for repairing various common rail injectors and pumps.
Benefits to Common rail injector test equipment 918A:
1. Five injector stander data came from Injector tightness test, Injector full load test, fuel injector oil-return testing, injector idle test, pre-spray injector test can be tested within five minutes.
2. Pump test can be finished within 4 minutes, pump testing items contain pump full load test, pump start-up test, pump load test, oil pump solenoid valves and metering valve test, pump standard data. EUI / EUP testing project contains EUI / EUP full load test, EUI / EUP in the load test, EUI / EUP idle test, EUI / EUP start the test, EUP / EUI standard data
3. Piezoelectric crystal injector test five data of injector within five minutes, injector tightness test, fuel injector full load test, fuel injector oil-return test, injector idle test
4. DIY data increases, testing reports, storage of test reports, customization of test report, poor reports, system error codes, tips of maintenance。
Difference between 918A and 918B: 918B with full set of Aids tool.
Technical SpecifiSHUMATTions of injector test SHUMATT HEUI 918
1. Important components |
Plunger fuel pump Flow | 16L/ min |
Oil Pressure | 20Mbar |
Diesel pressure | 40bar |
Flow sensor | Original Germany KOBO |
Injector Flow sensor | ≥700 ml/min |
Injector Flow sensor accuracy | 0.5 ‰ |
Flow sensor | 1pc |
Rail Fuel pressure regulator | Manual |
Quick start | Yes |
2. Software system |
HEUI Test | Yes |
HUEI Model | 235-2888128-6601 |
Injector Quick test | 5 min |
Injector Test Projects | 5 |
Injector Sealing test | Yes |
Injector Full load test | Yes |
Injector Middle load test | Yes |
Injector idle test | Yes |
Pre injection test | Yes |
Injector Data | Yes |
DIY Data | Support |
Test report | Support |
Test report save | Yes |
Test report Customization | Yes |
Adverse Report | support |
trouble code | support |
Maintenance Remind | support |
Screen | 19 inch LED display shows the inspection process, operation, test reports, bug reports |
3. Host control section |
Chipset | Intel ARM X9 |
USB port | 4 |
VGA port | 1 |
Operating system | WindsCE |
Design standards | Industrial control standards |
4. System filtration and protection |
Clogging reminder system | Yes |
Filters | 4 |
primary standard Filter | 2, Euro III standard |
secondary standard Filter | 1,Euro III standard |
engine oil filter | Yes |
engine oil filter | high pressure oil filter |
Cooling method | 2 synchronous cooling |
Fuel cooling method | Electric cooling fan blades |
Radiator numbers | 2 sets |
Radiator Power | 160W |
Fuel tank | Combined automatical classified tank |
engine oil tank capacity | 45L |
diesel oil tank capacity | 10L |
Oil accumulator tank | 3L |
5. Ancillary apparatus |
Host voltage | 380V |
Engine Oil Motor power | 7.5kw |
Diesel oil motor power | 1.5KW |
inverter | 7.5kw |
Stabilizer | 500AV |
Display | 21 inch LED screen |
mist eliminator | Yes |
6. Aids tool |
Injector Test Fixture | Yes |
Oil collector | Yes |
Full set of Aids tools | Yes |
7. Update and warranty |
Update method | U disk update |
Warranty | 3 years |
Data add | DIY manually add and U disk update |
Upgrade deadline | Lifetime Free |
8. Packing Of SHUMATTerpillar HEUI Injector test equipment 918B |
Size | 1900*830*1600mm |
GW | 850KG |
NW | 800KG |
Shipping | Deliver to any port of china freely |
Packing | Environmentally friendly packaging, export fumigation wooden plywood |
